Conducting Electrical Tests for PV Systems



Content Type Icon

CONTENT TYPE

VR, ILV, Interactive Modules

Duration Icon

DURATION

3 Hours

Target Audience Icon

TARGET AUDIENCE

Technician

Course Delivery Icon

COURSE DELIVERY

VR and Web-based

IACET Credits Icon

Credits : - 0.3

Learn, assess, evaluate, and implement training process

About the Course:

This microcredential trains PV technicians to perform essential electrical tests during photovoltaic (PV) system installation and commissioning. Learners will use VR simulations to practice insulation resistance checks, polarity verification, DC string testing, continuity checks, and AC voltage verification. Emphasis is placed on safety, accuracy, and compliance with NEC and industry standards. Technicians seeking structured career advancement can enroll in our Solar Training Program for certification-focused, job-ready training.

Learning Objectives:

  • Perform insulation resistance testing to verify system safety.
  • Conduct polarity testing to ensure correct wiring orientation.
  • Measure DC string open-circuit voltage (Voc) and confirm design compliance.
  • Test DC string maximum power current (Imp) under operational conditions.
  • Perform DC string short circuit (Isc) testing for current validation.
  • Conduct continuity testing to ensure wiring integrity.
  • Verify wire termination torque to manufacturer and code specifications.
  • Perform AC voltage testing for grid connection readiness.

Course delivered via LMS and requires an Oculus VR headset for hands-on VR simulations.

PV technician conducting electrical tests for solar system commissioning



Workforce Development

Hands-on PV system commissioning and electrical testing training

At ImmerseLearn, we prepare solar technicians to validate PV system performance and safety through accurate testing and measurement. This microcredential emphasizes real-world testing practices, proper tool use, and code compliance.

Insulation and Polarity Verification −
Learn to test insulation resistance and verify polarity to ensure system safety and prevent miswiring issues.
DC String Testing +
Develop skills in conducting Voc, Isc, and Imp tests to confirm PV string output and identify performance deviations.
Continuity and Torque Checks +
Practice continuity testing and torque verification on wire terminations to guarantee electrical integrity and reliability.
AC System Validation +
Perform AC voltage checks at the inverter and grid connection points to confirm safe and correct system integration.

By completing this microcredential, PV technicians will gain the technical knowledge and hands-on skills needed to perform critical electrical tests, ensuring safe, compliant, and high-performing PV system installations. Complete your pathway with our PV Certification Training Program to gain industry-recognized credentials.
